Thanks to its highly intelligent systems, the FlexiROC T40 computerized tophammer drill rig offers significant benefits to operators and businesses. It is primarily designed for quarries, where efficiency and environmental impact are paramount. By providing precise, real-time power for each stage of the drilling operation, the rig optimizes fuel consumption without compromising productivity. These innovative features ensure it is a flexible drill rig suitable for a wide range of tasks.

Functions and Features:

Greatly improved operator comfort and usability interface.

Advanced, fuel-efficient control system.

Precise Hole Navigation System (HNS) with comprehensive data logging supports drilling and blasting operations throughout the quarrying process.

推荐钻孔直径:
孔径范围 76 – 127 mm
适用钻具规格 T45、T51
换杆器能力:
孔深约29 m
液压凿岩机:
COP 2560
最大冲击功率 25 kW
回转速度 0 – 110 rpm
扭矩，最大 1 180 Nm
发动机:
卡特彼勒
水冷涡轮增压柴油发动机 CAT C7
额定功率(2200 rpm时） 168 kW
排放标准满足Stage3和Tier III标准
燃油箱:
容量 370 l
螺杆式空压机
工作压力，最大 10.5 bar
排量 FAD 136 l/s
钻臂:
形式折叠臂
推进梁:
推进方式油缸式
推进梁总长 7 140 mm
推进行程 4 240 mm
推进补偿 1 400 mm
推进速度，最大 0.92 m/s
推进力，最大 20 kN
拉拔力，最大 20 kN
行走:
行走速度，最大 3.6 km/h
驱动力 142 kN
爬坡能力 30°(大于20°时，建议配绞盘)
履带架摆动角度 ±12°
离地间隙 455 mm
运输尺寸:
总重量，约(不含选购件) 14 500 kg
宽度 2 490 mm
长度 11 000 mm
高度 3 130 mm

AtlasT40

┇ Hole: 76 – 127 mm ┇ Drill Tool: T45, T51 ┇ Depth: Approximately 29 m ┇ Engine: Caterpillar CAT C7 ┇ Power: 168 kW ┇ Pressure: 10.5 bar
